HR series Horizontal mechanical double stage pusher centrifuge for salt separation
Structure and working principle
Popular Salt Refining Plant Centrifuge The horizontal two-stage pusher centrifuge pump combination, Pushing the base, bearing assembly, the drum, mesh, chassis and electrical control boxes and other component parts. Push the feeding mechanism, the drum, screen and other parts through the bearing assembly supported on the base. The base oil tanks are equipped with oil cooler. Pump combination is also the base of support, the pump inside the oil pool, rotary connection through Triangle tape and host pulley. The electronic control box, a separate system, installed in the appropriate position with the host.
Host at full speed, the suspension through the feed tube into the allocated disk mounted on the outer drum under the influence of centrifugal force, suspension liquid uniform distribution of the drum plate online, the liquid phase by the board net net gap and drumfilter holes and escape, while the solid phase was retention ring residues layer formed in the plate online. Reciprocating motion of the inner drum, the residues along the drum axis goes forward, unloaded outside the drum set before the trough.
Specification
|
Item
|
HR400-N | HR500-N | HR630-N | HR800-N | HR1000-N |
| Inner/Outside basket diameter(mm) | 337/400 | 410/500 | 560/630 | 720/800 | 920/1000 |
|
Length of filtering(mm) (Inner/Outside basket) |
160/160 | 180/180 | 240/240 | 300/300 | 240/320 |
| Inner/Outside basket Speed(r/min) | 1500-2200 | 1200-2000 | 1000-1800 | 800-1600 | 650-1250 |
| Separating factor | 503-1083 | 402-1118 | 352-1140 | 286-1145 | 236-875 |
| Length stroke(mm) | 40 | 50 | 50 | 50 | 50 |
| Frequency of stroke(time/min) | 30-80 | 50-70 | 30-80 | 30-80 | 20-70 |
| Main motor power(Kw) | 11 | 30-45 | 37-55 | 55-75 | 75-90 |
| Oil pump motor power(Kw) | 5.5 | 22 | 30 | 45 | 45 |
| Production capacity(t/h) | 1-8 | 5-15 | 8-25 | 15-40 | 18-50 |
| Overall dimension L*W*H(mm) | 2460*1286*1030 | 3590*1430*1642 | 3500*1760*1265 | 3700*1800*1450 | 4200*1900*1900 |
| Weight(Kg) | 2480 | 3500 | 4000 | 6000 | 12000 |
Sketch map of pistons of two ends push material centrifuge operation
Main Characteristics
This type of centrifuge is well used to separate suspension with its solid size is over 0.1mm and density is over 30%. It can be used in chemical, light, pharmacy and food industry to produce sodium chloride ammonium fluoride ammonium bicarbonate, sodium sulphate, urea, caffeine, polyethylene, polystyrene, oxalate, nitrate.
It has following distinctive features:
1. While there is a high demand to the purity of the products, the centrifuge can wash them and drain out the washing liquid and the mother liquid separately.
2. Low and even consumption of the power.
3. Could be operated continuously and steadily, which capacity is great.
4. Because of its high separating factor, it could be dehydrated fully in the two baskets. So the filter cake will contain less moist.
Application
This type of centrifuge is well used to separate suspension with its solid size is over 0.1mm and density is over 30%.It can be used in chemical,light,pharmacy and food industry to produce sodium chloride ammonium fluoride ammonium bicarbonate, sodium sulphate, urea, caffeine, polyethylene, polystyrene, oxalate, nitrate.
Competition
Quality and experience.We are top centrifuge supplier in China,our designs and structures are analogous to world leader brands. My price is not the lowest in China,but we promise,for the same quality and collocation,my price is the most favorable,for the same price,my quality is definitely superior to other brands.
FAQ
1. How do you protect the quality?
As state owned enterprise with more than 100years history, we have strict operation policy,advanced processing machines to guarantee the precision, workers with operation license, related components are from world famous brand, Series of test and inspection are done in the whole producing stage.
2. What is your advantage compared with your competitors?
Quality and experience, we are top centrifuge supplier in China,our designs and structures are analogous to world leader brands.
3. Is your price competitive?
My price is not the lowest in China, but we promise, for the same quality and collocation, my price is the most favorable, for the same price, my quality is definitely superior to other brands.
4. Will you dispatch technicians for installation and commissioning?
Yes, we will upon required.
5. Do you have OEM service? Do you supply the parts?
Yes, we do, as long as you provide us your drawing and detailed requirements.
6. Do you have agents or service centre abroad?
We have some partnership in several countries as Indonesia, Brazil, USA.
7. How can we visit your factory?
If you come from aboard, air to shanghai or Nanjing airport, or if you arrive shanghai, you can take bullet train. - If you come from domestic city, air or train directly to Nanjing Nan or WUXI east, we will pick you up both from airport or railway station.
8. Can we visit your end user or contact them?
Yes, we will provide you the name list, and arrange the visit after their approval.
