Platform Bag Shaking Vertical Peeler Centrifuge SS304

Platform Bag Shaking Vertical Peeler Centrifuge SS304

  • High Light

    Vertical Peeler Centrifuge SS304


    1500rpm Vertical Peeler Centrifuge


    SS304 chemical centrifuge machine

  • Product Name
    Bag Shaking Centrifuge
  • Operation
    Continuous Automatic
  • Loading Capacity
  • MOC
    SS304/SS316/DSS Etc.
  • Grade
  • Application
  • Certification
    ISO/CE Etc.
  • Centrifugal Type
    Centrifugal Filtration
  • Place of Origin
  • Brand Name
  • Certification
  • Model Number
  • Minimum Order Quantity
    1 set
  • Price
    USD30000-80000/SET FOB SHANGHAI
  • Packaging Details
    Standard export package,
  • Delivery Time
    60-90 days after down payment
  • Payment Terms
    L/C, T/T, Western Union
  • Supply Ability
    300 sets/month

Platform Bag Shaking Vertical Peeler Centrifuge SS304

Platform Bag Shaking Bottom Scraper Discharge Centrifuge for pharmaceutical, food, additives and chemical






Basket diameter(mm) 800 1000 1250 1350 1400 1600
Basket height(mm) 400 500 500/630 630 700 800/720
Basket Volume(L) 80 165 310/400 445 560 800/720
Loading capacity(Kg) 100 210 400/520 534 672 1000/870
Max.speed(r/min) 1500 1200 1000/1200 1200 1150 850


Working Principle:

Raw material through feeding tube feeding into high speed rotating basket, under centrifugal force, liquid phase will drain out through liquid exit, solid phase will be filter on the surface of filter bag, formed as filter cake, stop feeding raw material, cleaning filter cake, after cleaning water drain out, rotating scraper will scrap filter cake and discharge to bottom. There have slight residue cake on the surface of filter bag which scraper could not scrap out, pneumatic bag-shaking device will reciprocating motion up and down, shaking residue cake out and discharge, most of residue cake could be clear out totally.


Function introduction

PPSBDL series Bag-Shaking Bottom Scraper Discharge Centrifuge is mainly working for solid-liquid separation with scraper discharge and bag shaking mode to clear out residue filter cake, 99% residue filter cake could be clear out totally, it could avoid to confound different production batches, meanwhile, this could solve the problem about residue filter cake influence filtering speed rate. This kind of centrifuge is mainly applied in pharmaceutical, food, additives and chemical industries liquid- solid separation of crystallization material.

Platform Bag Shaking Vertical Peeler Centrifuge SS304 0


Platform Bag Shaking Vertical Peeler Centrifuge SS304 1



Main Features

1. Bag-shaking device to clear out residue filter cake

2. Disassemble drum liquid blocking plate, auto-locking, easy replace of filter bag.

3. Built-in gas cylinder design, cramped construction.

4. Self-cooling rotation joint, reliable operating and running.

5. Totally enclosed type solid discharge hopper design, isolated material part with driving device
