PPCC Horizontal Peeler Centrifuge Industrial Centrifugal Dryer For Starch

1 set
USD60000-100000/set FOB Shanghai
PPCC Horizontal Peeler Centrifuge Industrial Centrifugal Dryer For Starch
Features Gallery Product Description Request A Quote
Type: Horizontal Peeler Centrifuge
Product Type: Automatic Centrifuge
MOC: SS304,316 As Option
Operation: Continuous Automatic
Discharge Type: GMP
Equipped: PLC System, Inverter
Application: Starch, Calcium Carbonate, And Others
Voltage: Customized
High Light:

PPCC Horizontal Peeler Centrifuge


Continuous Horizontal Peeler Centrifuge


industrial centrifugal dryer PPCC

Basic Infomation
Place of Origin: China
Brand Name: Hanpu
Certification: ISO,CE
Model Number: PPCC
Payment & Shipping Terms
Packaging Details: Standard export package,
Delivery Time: 60-75 days after down payment
Payment Terms: L/C, T/T, Western Union
Supply Ability: 300 sets/month
Product Description


PPCC Series Peeler Centrifuge Industrial Centrifugal Dryer for Starch


Brief introduction

PPCC automatic centrifuge is solid-liquid separation equipment which adopts continuous operation and intermittent discharging. The machine is controlled by PLC. Its braking system adopts dynamic braking and regenerative braking. Through such procedures as product level detection, speed inspection, shaft temperature and vibration monitoring, the whole separation process is automatic circulation and working (including feeding, dehydration, washing, discharging, etc.) Also manual operation mode is available which can be changed over from full-automatic mode by customer’s will.



Drum diameter


Drum volume (L) Loading capacity (kg)

Max speed


Max separation factor

Motor power

PPCC-53 600 41 53 2400 1931 18.5
PPCC-130 800 100 130 1500/1800 1007/1448 30
PPCC-230 1000 180 230 1400 1096 37
PPCC-270 1050 210 270 1400/1700 1150/1696 37
PPCC-430 1250 335 430 1200 1006 55
PPCC-585 1350 450 585 1200 1086 55
PPCC-900 1600 700 900 950 808 90
Main Characteristics
1.It is fully conformed to GMP,CGMP and meet the requirements of sterile raw medicine produciton.

2. With absolute isolation between power area and process area. It is suitable for occasion when customer requires high quality cleaning to avoid the contamination to product.
3. The out shell bucket can be opened, so the whole internal parts could be observed and easy for touch wiping and cleaning.
4. Perfect CIP system can be carried out to wash the internal parts of centrifuge to avoid cross contamination which are not easy to clean.
5. Unique pneumatic counter-pulse device is equipped, which can remove remnant filter cake as much as possible.
6. Totally-enclosed structure equipped with inert gas protection is adopted to be used in ex-proof I section.
7. The automatic residual cakes removing device is optional (have owned the national patent).
PPCC Horizontal Peeler Centrifuge Industrial Centrifugal Dryer For Starch 0

Flow Chart
PPCC Horizontal Peeler Centrifuge Industrial Centrifugal Dryer For Starch 1
Working principle
Feeding nitrogen or other inertgas into the host machine, after reaching the pre-determined content, when predetermined target is met and drum speed is suitable for feeding, feeding valve will be open automatically and product level detection begins to work.
When layer thickness is thick enough to reach the product detection slab, feeding valve closes to stop feeding. Under the effect of centrifugal force, most of the liquid in suspension is thrown out through filter cloth(or filter net) and the holes on drum wall then flows into mother liquid tank through horizontal liquid outlet(initial filter). With product dehydration going on, centrifuge will automatically slow down to washing speed according to technical requirement for washing.
Washing valve opens automatically With washing liquid rising to a certain height, washing valve closes and centrifuge speeds up automatically for further dehydration(secondary filter).
After a moment of operation,product will be fully dried. Then discharging will be in process.Then discharging valve opens and discharging cylinder begins to work when centrifuge automatically slows down to predetermined speed. With scraper rising spirally and automatically, solid product is scraped down into the hopper equipped with spiral discharger: With constant motion of spiral discharger, product is pushed out and discharged through valve.
Scraper rises closer to filter cloth with a certain distance till the bar on scraper device approaches proximity switch to stop
scraper rising then retreats quickly after a short stay(about 15s)then enters next cycle.
PPCC Horizontal Peeler Centrifuge Industrial Centrifugal Dryer For Starch 2

Processing equipment
PPCC Horizontal Peeler Centrifuge Industrial Centrifugal Dryer For Starch 3

1. How do you protect the quality?
As state owned enterprise with more than 100years history, we have strict operation policy,advanced processing machines to guarantee the precision, workers with operation license, related components are from world famous brand, Series of test and inspection are done in the whole producing stage.

2. What is your advantage compared with your competitors?

Quality and experience, we are top centrifuge supplier in China,our designs and structures are analogous to world leader brands.

3. Is your price competitive?

My price is not the lowest in China, but we promise, for the same quality and collocation, my price is the most favorable, for the same price, my quality is definitely superior to other brands.

4. Will you dispatch technicians for installation and commissioning?

Yes, we will upon required.

5. Do you have OEM service? Do you supply the parts?

Yes, we do, as long as you provide us your drawing and detailed requirements.

6. Do you have agents or service centre abroad?

We have some partnership in several countries as Indonesia, Brazil, USA.

7. How can we visit your factory?

If you come from aboard, air to shanghai or Nanjing airport, or if you arrive shanghai, you can take bullet train. - If you come from domestic city, air or train directly to Nanjing Nan or WUXI east, we will pick you up both from airport or railway station.

8. Can we visit your end user or contact them?

Yes, we will provide you the name list, and arrange the visit after their approval.


Tips:China decanter centrifuges suppliers,scraper bottom discharge centrifuge,Tapioca starch centrifuge
