Starch Factory PPCS PLC Control Automatic Peeler Centrifuge
Brief production
PPCS siphon centrifuge is a new type of product that is developed on the basis of the ordinary peeler centrifuge. Based on the siphon principle, this product discharges the filtrate out via a siphoning device or skimming device. The filtering impetus can be changed by adjusting the liquid level at the suction inlet of the siphon pipe (skimming pipe) to further regulate the filtering rate, handling capacity, cake moisture and washing effect. A back-flushing device is configured to realize regeneration of the filter cloth and improve the separation effect. With back-flush, scouring, siphoning and other functions by configuring special devices, the filter cloth can be regenerated completely.
Main features
1. With absolute isolation between power area and process area. It is suitable for occasion when customer requires high quality cleaning to avoid the contamination to product.
2. The out shell bucket can be opened, so the whole internal parts could be observed and easy for touch wiping and cleaning.
3. Perfect CIP system can be carried out to wash the internal parts of centrifuge to avoid cross contamination which are not easy to clean.
4. Unique pneumatic counter-pulse device is equipped, which can remove remnant filter cake as much as possible.
5. Totally-enclosed structure equipped with inert gas protection is adopted to be used in ex-proof I section.
6. The automatic residual cakes removing device is optional (have owned the national patent).
Specification
| Itemmodel | PPCS-26 | PPCS-140 | PPCS-250 | PPCS-260 | PPCS-500 | PPCS-1100 | PPCS-1800 | PPCS-2400 |
|
Basket diameter(mm) |
450 | 800 | 1000 | 1050 | 1250 | 1600 | 1800 | 2000 |
| Basket Height(mm) | 300 | 450 | 500 | 500 | 630 | 1000 | 1250 | 1400 |
| Basket volume(L) | 21 | 110 | 200 | 210 | 335 | 879 | 1390 | 1923 |
| Loading Capacity(kg) | 26 | 140 | 250 | 260 | 500 | 1100 | 1800 | 2400 |
| Max Speed(r/min) | 2600 | 1500 | 1400 | 1400 | 1200 | 950 | 900 | 950 |
| Maximum separating factor | 1700 | 1007 | 1095 | 1150 | 1006 | 808 | 815 | 1008 |
| Motor power(Kw) | 15 | 37 | 45 | 45 | 75/90 | 132 | 160 | 200 |
| Dimensions (including shock absorb) | 1800*1375*1902 | 2439*1900*2150 | 3050*2400*2192 | 3050*2400*2192 | 3875*2500*2612 | 5620*3200*3930 | 5862*3600*3910 | 7577*3700*4053 |
| Weight(kg) | 2500 | 5800 | 6200 | 7800 | 8000 | 20000 | 24500 | 35000 |
| Weight including platform(Kg) | 2500 | 10800 | 13200 | 15000 | 16000 | 39000 | 52500 | 62000 |
Application
The siphon-type peeler centrifuge is applicable to the occasions involving large-scale production and requiring low cake moisture and sufficient washing, and therefore is commonly used for the separation of starch, sodium bicarbonate, potassium chloride, calcium phosphate and other materials. Currently, it has been widely applied in such industries as pharmaceutical production, food production, bio-engineering and chemical engineering.
Processing equipment
Guarantee
Hanpu Centrifuge has been dedicated to producing machinery and types of equipment and carrying out facility construction, pursuing the best quality, and producing the best product at the same time.We are committed to rewarding you with better quality in return for our interest in and faith. We will do our utmost for one more stepping forward, based on our infinite services and trust in customers.
FAQ
1. How do you protect the quality?
As state owned enterprise with more than 100years history, we have strict operation policy,advanced processing machines to guarantee the precision, workers with operation license, related components are from world famous brand, Series of test and inspection are done in the whole producing stage.
2. What is your advantage compared with your competitors?
Quality and experience, we are top centrifuge supplier in China,our designs and structures are analogous to world leader brands.
3. Is your price competitive?
My price is not the lowest in China, but we promise, for the same quality and collocation, my price is the most favorable, for the same price, my quality is definitely superior to other brands.
4. Will you dispatch technicians for installation and commissioning?
Yes, we will upon required.
5. Do you have OEM service? Do you supply the parts?
Yes, we do, as long as you provide us your drawing and detailed requirements.
6. Do you have agents or service centre abroad?
We have some partnership in several countries as Indonesia, Brazil, USA.
7. How can we visit your factory?
If you come from aboard, air to shanghai or Nanjing airport, or if you arrive shanghai, you can take bullet train. - If you come from domestic city, air or train directly to Nanjing Nan or WUXI east, we will pick you up both from airport or railway station.
8. Can we visit your end user or contact them?
Yes, we will provide you the name list, and arrange the visit after their approval.
Tips:Peeler Centrifuge,Starch Factory,automatic centrifuge filter system
