MVR Evaporator Solution for Sugar Evaporation & Syrup Concentration
Cane & beet sugar mills — concentrate thin juice to 60–70°Bx syrup with low energy, low color (ICUMSA), and stable crystallization.
Hanpu delivers EPC turnkey MVR evaporator systems for sugar evaporation and syrup concentration. Our designs integrate falling-film or forced-circulation effects to protect heat-sensitive juices, curb color formation, and cut steam demand. Whether you process cane sugar or beet sugar, we help you convert thin juice into thick juice / syrup for the boiling house / pan station, improving pan capacity and crystallization stability.
Common challenges in sugar evaporation
High steam consumption, sucrose inversion and caramelization at high temperature, scaling/fouling (e.g., CaCO₃, silica), rising viscosity at higher Brix, and off-spec condensate (odor/COD) that limits reuse. MVR solves these via low-temperature evaporation, optimized ΔT, and condensate polishing.
Why Hanpu MVR for sugar mills
|
Process-specific design (cane/beet)
|
Low specific energy (electric-driven)
|
Low color (ICUMSA) at target Brix
|
Anti-scaling design & CIP
|
What you’ll get with us
- A complete process package with heat & material balance and CAPEX/OPEX analysis
- Target 60–70°Bx thick juice with temperature control for product quality
- Falling-film / forced-circulation / hybrid selection based on viscosity & scaling risk
- Condensate stripping/polishing for reuse in process water/boiler makeup
- Compact skids, PLC/SCADA automation, CE/ASME compliance, retrofit-ready with existing MEE
Delivery workflow
Feed & targets → Lab/pilot (optional) → Process design & heat balance → Detailed engineering & fabrication → Installation & commissioning → Performance test & training → Maintenance & spares strategy
Application scope
Cane thin juice evaporation · Beet thin juice to thick juice (syrup) · Syrup concentration for pan station · Condensate reuse and water-saving · Retrofit of multi-effect lines.
Frequently Asked Questions
Have questions about MVR sugar evaporation? Here are common FAQs. If you don’t see yours, contact us.
Q1: MVR vs. steam-driven multi-effect—how to choose in a sugar mill?
MVR reuses vapor via mechanical compression, ideal where electricity is competitive or steam is limited. Multi-effect uses live steam cascaded across effects. We compare your energy prices, evaporation duty, Brix and temperature limits to select or combine both.
Q2: Can MVR reach 60–70°Bx without excessive color formation?
Yes. Low-temperature operation and controlled ΔT help minimize sucrose inversion and caramelization, achieving low ICUMSA color at target Brix.
Q3: Which evaporator body should I choose—falling-film or forced-circulation?
Falling-film suits clean, heat-sensitive juice with lower viscosity; forced-circulation handles higher viscosity and scaling risk. We also offer hybrid trains to balance energy and operability.
Q4: What about condensate quality and reuse?
We add condensate stripping/polishing to meet reuse specs (odor/COD), enabling use as process water or boiler/cooling makeup and improving mill water balance.
Q5: Can your MVR retrofit my existing multi-effect line?
Yes. MVR can debottleneck existing effects or operate as a stand-alone concentrator feeding the pan station. We integrate controls, hydraulics, and CIP with your boiling house.
Related keywords
MVR sugar evaporation, syrup concentration, thin juice to thick juice, cane sugar, beet sugar, falling-film evaporator, forced-circulation evaporator, ICUMSA color, Brix, pan station, crystallization, condensate reuse, multi-effect retrofit.
