Flat Plate Scraper Bottom Discharge Centrifuge Machine

Flat Plate Scraper Bottom Discharge Centrifuge Machine

  • High Light

    250kg bottom discharge centrifuge machine


    PPSBD bottom discharge centrifuge machine


    Continuous basket centrifuge

  • Product Name
    Scraper Bottom Discharge Centrifuge
  • Operation
    Continuous Automatic
  • Loading Capacity
  • Collocation 1
    Hydraulic System
  • Collocation 2
    Level Detector
  • Application
  • Certification
    ISO/CE Etc.
  • Centrifugal Type
    Centrifugal Filtration
  • Place of Origin
  • Brand Name
  • Certification
  • Model Number
  • Minimum Order Quantity
    1 set
  • Price
    USD30000-80000/SET FOB SHANGHAI
  • Packaging Details
    Standard export package,
  • Delivery Time
    60-90 days after down payment
  • Payment Terms
    L/C, T/T, Western Union
  • Supply Ability
    300 sets/month

Flat Plate Scraper Bottom Discharge Centrifuge Machine

 Flat Plate Scraper Bottom Machine Discharge Automatic and continuous Centrifuge


Function introduction

PPSBD series centrifuge is a type of centrifugal separation machinery with high scientific content and several configuration options are available.Featuring asepsis,sanitation,enclosed explosion-pfoof,multiple safety protections and several configuration options,this series centrifuge is controlled by a fully automatic program,and has been widely used in such industries as pharmacy,fine chemistry and food.


Technical parameters

Model/Item Basket volume(L) Loading Capacity(kg) Max. Speed(r/min) Maximum separating factor

Motor power


Size (including shock absorb) (mm)
PPSBD60S 45 60 1800 1064 5.5 1700*1200*1700
PPSBD135S 100 135 1500 1007 7.5 1700*1400*1960
PPSBD180S 140 180 1080 652 15 1968*1500*2060
PPSBD250S 190 250 1200 805 15 1968*1200*2400


Main Features


1. Platform base structure could lower the center of gravity and stabilize the machine. No foundation consruction makes convenient installation and repairing

2. Platform base with liquid damping isolators-Applying the liquid damping improves performance of vibration absorption in centrifuge

Inclined feed disk: we discarded the centeal feed or side feed method.

3. Air recoil and pneumaticauxiliary scraper: this technilogy effectively reduces the solids remained in the basket and effective resume the performance of the filter cloths

4. Nitrogen protection system: ensuing the safety during the operation.

5. Multipie safety protection devices: over-vibration protection, over-current protection, themal control Protection, cake layer controller. protection


Working Principle:

Raw material through feeding tube feeding into high speed rotating basket, under centrifugal force, liquid phase will drain out through liquid exit, solid phase will be filter on the surface of filter bag, formed as filter cake, stop feeding raw material, cleaning filter cake, after cleaning water drain out, rotating scraper will scrap filter cake and discharge to bottom. There have slight residue cake on the surface of filter bag which scraper could not scrap out, pneumatic bag-shaking device will reciprocating motion up and down, shaking residue cake out and discharge, most of residue cake could be clear out totally.


Flat Plate Scraper Bottom Discharge Centrifuge Machine 0

Flat Plate Scraper Bottom Discharge Centrifuge Machine 1

Flat Plate Scraper Bottom Discharge Centrifuge Machine 2




Flat Plate Scraper Bottom Discharge Centrifuge Machine 3

Company Profile

Jiangsu Hanpu Mechanical Technology Co., Ltd. is a project engineering company jointly established by Jiangsu Saideli Pharmaceutical Machinery Co., Ltd., Jiangsu Zhongyi Environmental Technology Co., Ltd., FERREO A/S in Denmark, Shanghai Jiaotong University and Nanjing Kingreat Machinery Co., Ltd. Hanpu main projects include but are not limited to: MVR evaporation system, powder washing salt and vacuum salt production project, oil tank sludge cleaning project, landfill leachate treatment project, plant/animal oil processing production line, urban wastewater treatment project, various wastewater treatment projects, and CBD oil extraction production line. Technical support and transfer of API product technology package. The main products are centrifuge series, multi-effect and MVR evaporation and crystallization equipment, laser welding heat transfer board, lithium battery material mixing equipment, pressure vessel and titanium, zirconium, nickel, and other non-standard special equipment.


Our services

1. 12 months guarantee period from machine arriving date.

2. Our technicians could be dispatched for overseas service.

3. 7*24 hours technical consultation.

4. Your workers could get trained both in our factory and yours.

5. Routine tracing till the machine work properly will be done timely.

6. Your suggestions or any comments & reflection would be treated in priority.

7. Marketing team will visit you during our visit in your country if you require.
