PPSBD Series Stainless Steel Automatic Scraper Centrifuge

PPSBD Series Stainless Steel Automatic Scraper Centrifuge

  • High Light

    PPSBD scraper centrifuge

    ,

    Vertical scraper centrifuge

    ,

    Steel industrial centrifuge machine

  • Product Name
    Scraper Automatic Centrifuge
  • Operation
    Continuous Automatic
  • Equipped
    PLC System, Inverter
  • Color
    Steel
  • Grade
    GMP
  • Collocation
    Level Detector
  • Certification
    ISO/CE Etc.
  • Centrifugal Type
    Centrifugal Filtration
  • Place of Origin
    China
  • Brand Name
    Hanpu
  • Certification
    ISO,CE
  • Model Number
    PPSBDF
  • Minimum Order Quantity
    1 set
  • Price
    USD30000-80000/SET FOB SHANGHAI
  • Packaging Details
    Standard export package,
  • Delivery Time
    60-90 days after down payment
  • Payment Terms
    L/C, T/T, Western Union
  • Supply Ability
    300 sets/month

PPSBD Series Stainless Steel Automatic Scraper Centrifuge

PPSBD Series GMP Stainless Steel Scraper Automatic Centrifuge



Properties and Uses

PPSBD centrifuges have a perfect automatic performance and a large processing capacity. In accordance with users’
demand,procedures such as feeding, separating washing, dehydrating and discharging can all be automatically finished followed by remote control. It's suitable for solid-liquid separation of fibroid products as well as suspension which contains fine grains and medium size grains solid. For example: chemical industry products such as :gypsum,ammonium sulphide,bluestone,potassium chloride, borax, dyestuff, resin,pesticide and pharmaceutical products such as:salt, monosodium glutamate, food additive, starch, sugar, flavoring, antibiotic, vitamin and other industries such as mining and environmental protection ect.



Main Characteristics
1.The centrifuge adoptes whole enclosed structure with dependable seal facility which is filled with nitrogen to meet the
explosion proof demand.
2. Adopted with quick open clamshell structure and the optional swash plate distributor, products can be distributed evenly to reduce vibration caused by unbalanced distribution. with additional washing function, it has a better cleaning effect.
3. The motor is set on top of the machine and directly linked to main shaft which will bring higher transmission efficiency and reduce friction powders.
4. Pneumatic assisted scraper is adopted to remove the remnant filter cake and CIP system is optional to secure clarity to be in accordance with GMP Norm.
5. Frequency control system is adopted to assure a stable start-up. PLC is adopted to ensure a complete automatic process including feeding, filtering washing and discharging etc. lt adopts dynamic(regenerative) breaking without fiction powder pollution and friction heat so it is much safer
6. No need of human supervision. Following security systems are adopted: self-monitoring and protecting system, speed inspection, product level detection, over-vibration protection, over-heat ,protection for motor, mechanical and electric double interlock for scraper rotary and movement, interlock for lid's open and machine's running.



Specifications



Model PPSBD-F-800 PPSBD-F-1000

 PPSBD-F-1200



PPSBD-F-1250
Loading capacity (Kg)      135 180 320 400
Max.Speed(r/min) 1500 1080 970 1000
Maximum Separating factor 1007 652 631 698
Motor power(Kw) 1.5 15 18.5 18.5



Main Features

1. Adopt lid reversible structure or whole housing reversible structure,it is convenient for cleaning and maintenance.
2. Whole-sealing structure, inner machine, bearing seat, scraper are protected by nitrogen.
3. The tensity of polish is accurate, roughness of surface can reach Ra 0.2-0.4μm.
4. Structure is simple and seam is glazed, easy to clean.
5. The sealing of the main shaft is reliable and inspecting device is equipped, which can ensure no leaking.
6. CIP device is set reasonable, it can clean the centrifuge effectively with no cleaning angle.
7. Uperization is used in the machine.
8. Adopt frequency conversion controlling system, dynamic or regenerative braking.
9. Enclosed cover is set on the transmission device to avoid powder pollution during the process of transmission.



PPSBD Series Stainless Steel Automatic Scraper Centrifuge 0

PPSBD Series Stainless Steel Automatic Scraper Centrifuge 1

PPSBD Series Stainless Steel Automatic Scraper Centrifuge 2

Company Profile

Jiangsu Hanpu Mechanical Technology Co., Ltd. is a project engineering company jointly established by Jiangsu Saideli Pharmaceutical Machinery Co., Ltd., Jiangsu Zhongyi Environmental Technology Co., Ltd., FERREO A/S in Denmark, Shanghai Jiaotong University and Nanjing Kingreat Machinery Co., Ltd. Hanpu main projects include but are not limited to: MVR evaporation system, powder washing salt and vacuum salt production project, oil tank sludge cleaning project, landfill leachate treatment project, plant/animal oil processing production line, urban wastewater treatment project, various wastewater treatment projects, and CBD oil extraction production line. Technical support and transfer of API product technology package. The main products are centrifuge series, multi-effect and MVR evaporation and crystallization equipment, laser welding heat transfer board, lithium battery material mixing equipment, pressure vessel and titanium, zirconium, nickel, and other non-standard special equipment.



Our services

1. 12 months guarantee period from machine arriving date.

2. Our technicians could be dispatched for overseas service.

3. 7*24 hours technical consultation.

4. Your workers could get trained both in our factory and yours.

5. Routine tracing till the machine work properly will be done timely.

6. Your suggestions or any comments & reflection would be treated in priority.

7. Marketing team will visit you during our visit in your country if you require.
