Large Capacity Horizontal Scraper Peeler Centrifuge SS304 For Sago Starch Plant

Large Capacity Horizontal Scraper Peeler Centrifuge SS304 For Sago Starch Plant
Features Gallery Product Description Request A Quote
Name: Horizontal Scraper Peeler Centrifuge
Moc: SS304,316 As Option
Discharge: Spiral Scraper Discharge
Equipped: PLC System, Inverter
Certificate: ISO
Application: Starch, Calcium Carbonate, And Others
Warrenty: 1 Year
Machinery Test Report: Provided
High Light:

Horizontal Scraper Peeler Centrifuge


Large Capacity Peeler Centrifuge


Scraper Peeler Centrifuge

Basic Infomation
Place of Origin: China
Brand Name: Hanpu
Certification: CE ISO
Model Number: 1.8*1.5M
Payment & Shipping Terms
Packaging Details: standard exported wooden case
Delivery Time: 45-60 working days
Supply Ability: 50sets per months
Product Description

Large Capacity Horizontal Scraper Peeler Centrifuge for Sago Starch Plant


This horizontal basket peeler centrifuge is a kind of solid liquid separation equipment with hydraulic system, It help you work in various application , like food, chemical , pharmacy. The solid mainly is the powder . like NaHCO3, kinds of starch,
It can automatic or manual finish the cyclic operation of feeding, separating, washing, discharging and screen
cleaning at full speed.




Item/Model PPCS-26 PPCS-140 PPCS-250



450 800 1000
Basket Height(mm) 300 450 500
Basket volume(L) 21 110 200
Loading Capacity(kg) 26 140 250
Max Speed(r/min) 2600 1500 1400
Maximum separating factor 1700 1007 1095
Motor power(Kw) 15 37 45
Dimensions (including shock absorb) 1800*1375*1902 2439*1900*2150 3050*2400*2192
Weight(kg) 2500 5800 6



Working principle

Feeding nitrogen or other inertgas into the host machine, after reaching the pre-determined content, when predetermined target is met and drum speed is suitable for feeding, feeding valve will be open automatically and product level detection begins to work.

When layer thickness is thick enough to reach the product detection slab, feeding valve closes to stop feeding. Under the effect of centrifugal force, most of the liquid in suspension is thrown out through filter cloth(or filter net) and the holes on drum wall then flows into mother liquid tank through horizontal liquid outlet(initial filter). With product dehydration going on, centrifuge will automatically slow down to washing speed according to technical requirement for washing.

Washing valve opens automatically With washing liquid rising to a certain height, washing valve closes and centrifuge speeds up automatically for further dehydration(secondary filter).

After a moment of operation,product will be fully dried. Then discharging will be in process.Then discharging valve opens and discharging cylinder begins to work when centrifuge automatically slows down to predetermined speed. With scraper rising spirally and automatically, solid product is scraped down into the hopper equipped with spiral discharger: With constant motion of spiral discharger, product is pushed out and discharged through valve.

Scraper rises closer to filter cloth with a certain distance till the bar on scraper device approaches proximity switch to stop
scraper rising then retreats quickly after a short stay(about 15s)then enters next cycle.



1. Compact designs
2. Automatic and stable operation
3. Scraper discharge with hydraulic system
4. PLC control
5. Adjustable procedures as to the request
6. Low moisture after from the machine
7. Supporting self-cleaning
8. Less noisy with high performance damper


The machine can also be used for heavy alkali, other materials, especially for the separation and washing dehydration of
materials with small solid particle size and difficult to separate, such as starch, calcium phosphate,etc., which can greatly
improve the operation status of separated materials such as heavy alkali and sodium bicarbonate.
