10tons/Day Salt Production Line Evaporation And Crystallization Mvr System

10tons/Day Salt Production Line Evaporation And Crystallization Mvr System

Products - Salt Production Line
  • High Light

    10tons/day salt production line

    ,

    mvr system salt production line

    ,

    mvr system salt processing line

  • Product Name
    Salt Production Line
  • Equipment
    Centrifuge, Dryer, Vacuum Filter, Etc.
  • Raw Material
    Sea Salt
  • Processing Type
    Dehydration And Drying
  • Warranty Period
    1 Year
  • After-sales Service
    Provide Overseas Service
  • Finished Product
    Table Salt, Industrial Salt, Etc.
  • Production Capacity
    10-1000 Tons/day
  • Place of Origin
    china
  • Brand Name
    Hanpu
  • Certification
    ISO/CE
  • Model Number
    Evaporator
  • Minimum Order Quantity
    1
  • Price
    150000
  • Packaging Details
    wooden
  • Delivery Time
    90-120

10tons/Day Salt Production Line Evaporation And Crystallization Mvr System

  • 10tons/Day Salt Production Line Evaporation And Crystallization Mvr System
  • 10tons/Day Salt Production Line Evaporation And Crystallization Mvr System
  • 10tons/Day Salt Production Line Evaporation And Crystallization Mvr System
Get Price Contact Now





Product Description





10tons/Day Salt Production Line Evaporation And Crystallization Mvr System 0
MVR SYSTEM INTRODUCTION
Mechanical vaporization re-compression system, which is called MVR which principle is to compress the second steam generated by evaporator by high efficiency steam compressor; this process transfers electric energy to eating energy and higher the pressure and temperature of second steam. The second steam with higher temperature will be sent to evaporation room to heat the product for evaporation. So the latent heat of vaporization of the second steam can be circularly used. Making use of less energy which is the mechanical energy of compressor blade wheel as the compression heat pump, energy is added into the heating medium and is circularly used in heating process. Under this circumstance, no need to add first steam as heating medium.
MVR SYSTEM ADVANTAGE
(1)Lowest energy consumption and operation cost, electricity consumption of one ton water’s evaporation is 15-50kw. (2)Temperature difference is small, heating is gentle, the loss of product is less.
(3)Compact structure and lower building cost; plant area is 50% less than that of traditional evaporator.
(4)Surrounding is friendly, no gas and no steam.
(5)Good adaptability in low loading condition, flexibility of operation is good and has a longer service life.
(6)Consumption of circular water is low and energy saving is obvious.
(7)No fresh steam is needed.
(8)Evaporation can be carried out under 40℃ and equipment need not to be frozen, specially suitable for thermal activity products.

Why Choose This Product

A plant which produces vacuum salt and mineral water together has great potential. On the one hand, the demand for refined salt has seen unprecedented growth over the past few years. On the other hand, packaged mineral water is a premium product that is priced much higher than pure packaged drinking water. In the USA, Europe and all other developed countries, vacuum salt is the only type of salt that is considered edible. This is because it is made by evaporating a pure and filtered salt solution, whereas refined salt is the result of grinding and washing raw solar salt from saturated brine. In the latter process it is not possible to make the salt entirely free from insoluble and soluble impurities such as sand and grit. This aspect of vacuum salt is a point of difference for the serious and discerning consumer. The process of making vacuum salt also produces distilled water, which can be converted into mineral water. For every tonne of vacuum salt produced, nearly 2,500 litres of drinking water is produced. Therefore, the cost of making vacuum salt is also shared by mineral water. The combination of these two products makes the vacuum salt project a huge money spinner. This results in a payback period of less than 2 years. The process involves continuous evaporation of the salt solution by allowing steam to enter the salt solution and condensing the steam to recover useful water. To save on steam consumption, multiple units are used in series so that the steam produced by one unit is evaporated in the next unit, thus eliminating the need to generate new steam. This process is continued over many effects, so that each kilogram of steam produced by the first effect generates many kilograms of steam from subsequent effects. The vapour produced by the last effect is condensed in a condenser with water from a cooling tower. The whole unit is initially under vacuum and thereafter the pressure of the whole system is thermodynamically stabilised. The vacuum is generated by using a suitable vacuum pump. The number of effects depends on the capacity of the plant in order to achieve optimum economy with minimum investment.
10tons/Day Salt Production Line Evaporation And Crystallization Mvr System 1
Effective number
1
2
3
4
5
6
7
8
Steam consumption
(t steam/ t water)
~1.04
~0.53
~0.36
~0.28
~0.23
~0.19
~0.17
~0.15
10tons/Day Salt Production Line Evaporation And Crystallization Mvr System 2
10tons/Day Salt Production Line Evaporation And Crystallization Mvr System 3
10tons/Day Salt Production Line Evaporation And Crystallization Mvr System 4
Application
10tons/Day Salt Production Line Evaporation And Crystallization Mvr System 5
Application

Hanpu's automatic salt machine production line (Model Number: Evaporator) is a perfect solution for large-scale sea salt production, certified with ISO/CE certification. This production line requires minimum order quantity of 1, with price of 150000. It is packed in wooden package and estimated delivery time is 90-120 days. The process type is dehydration and drying, and the equipment includes centrifuge, dryer, vacuum filter, etc. The installation area is 200-3000m2 and the power is 380V/50HZ. The raw material is sea salt, which can be processed into high-quality edible salt.

The whole production line is designed to produce high-quality edible salt with automatic operation. It is equipped with advanced technology, including centrifuge, dryer, vacuum filter and other parts. It is highly efficient and can process up to 3000m2 in a single run, offering a wide variety of sea salt products. The automation system ensures consistent quality of the sea salt produced. The production line is also equipped with safety measures to prevent any accidents.

The Hanpu's automatic salt machine production line is designed to provide a reliable and cost-effective solution for salt production. It is highly efficient and easy to maintain. It is ideal for large-scale salt production, providing consistent quality of the sea salt products. With its advanced technology and automated operation, it can offer a wide variety of high-quality edible salt products, making it the perfect choice for your salt production needs.

Applied to multiple areas, such as: "zero release" solution for industrial waste water, Evaporation and concentration for process industry, food fermentation (aginomoto, citric acid, starch and sugar), fine chemical (pesticide, synthetic dyes, organic pigments, paints, spice and essence, cosmetic), chlorine chemical (salt water concentration), seawater desalt and metallurgical industry, etc.
Company Profile
10tons/Day Salt Production Line Evaporation And Crystallization Mvr System 6
10tons/Day Salt Production Line Evaporation And Crystallization Mvr System 7
10tons/Day Salt Production Line Evaporation And Crystallization Mvr System 8
10tons/Day Salt Production Line Evaporation And Crystallization Mvr System 9
Established in 2019,Jiangsu Hanpu Machinery Engineering Technology Co., Ltd. is a subsidiary of Jiangsu Saideli Machinery Group.It is a professional enterprise engaged in the treatment of industrial waste water and gas,as well as evaporating crystallization, drying, filtration, and heat transfer in the field of multi-process production,together with the research and development and manufacturing of technical equipment.
Located in Junmin Road, Huangqiao Industrial Park, Taixing City, Jiangsu Province,the group has four major production bases, covering an area of 532800 square meters. Currently,there are 1580 employees, including 568 engineering technical personnel and professional technicians. We have fixed assets of 2 billion yuan and annual sales of 2.8 billion yuan.
The main products of the group include MVR evaporators, multi effect evaporators, centrifuges, reaction kettles, crystallizers, heat exchangers, PILLOW PLATES, Roots compressors, with various supporting fluid equipment.The enterprise has got ISO9001/2015 system certification, CE certification, ISO14001:2004 environmental management system certification, possesses A1 and A2 pressure vessel manufacturing qualifications, A2 pressure vessel design qualifications, and owns over 100 invention patents and utility model patent technologies. Also,we possess the right to self operate import and export trade.
The company's product quality, advanced technology, and comprehensive after-sales service have been widely recognized around the world, with a high market share. Various series of centrifuges account for 60% of the Chinese market and are exported to more than 50 countries and regions, including Germany, the United Kingdom, Italy, Denmark, Switzerland, the United States, Canada, Australia, Mexico, Brazil, Argentina, Chile, Colombia, Russia, Ukraine, Romania, India, Indonesia, Vietnam, Thailand, South Africa, Egypt, Cameroon, etc.
With the goal of "innovating products through technology, pursuing excellence in quality, serving customers with integrity and perfection", the company manufactures high-tech, highly automated, safe, and energy-saving equipment to become a first-class manufacturer of evaporation and fluid equipment in China.
10tons/Day Salt Production Line Evaporation And Crystallization Mvr System 10
10tons/Day Salt Production Line Evaporation And Crystallization Mvr System 11
10tons/Day Salt Production Line Evaporation And Crystallization Mvr System 12
10tons/Day Salt Production Line Evaporation And Crystallization Mvr System 13
10tons/Day Salt Production Line Evaporation And Crystallization Mvr System 14
FAQ
1. who are we?
We are based in Jiangsu, China, start from 2019,sell to North America(30.00%),South America(20.00%),Western Europe(10.00%),Africa(10.00%),Northern Europe(7.00%),Oceania(5.00%),Eastern Europe(5.00%),Mid East(5.00%),South Asia(3.00%),Southeast Asia(3.00%),Southern Europe(2.00%). There are total about 11-50 people in our office.

2. how can we guarantee quality?
Always a pre-production sample before mass production;
Always final Inspection before shipment;

3.what can you buy from us?
Dimple Plate, Reactor, Centrifuge

4. why should you buy from us not from other suppliers?
The company has a national functional office and facilities as a scientific research bureau. The research center now has 5 doctor tutors, 8 professional engineers, 11 senior engineers, 42 engineers and 68 assistant engineers making it a leading specialized

5. what services can we provide?
Accepted Delivery Terms: FOB,CFR,CIF,EXW,DDP,DDU；
Accepted Payment Currency:USD,EUR;
Accepted Payment Type: T/T,L/C,PayPal,Western Union;
Language Spoken:English,Spanish
