Multi Effect Salt Production Line For Sodium Chloride Industrial

Multi Effect Salt Production Line For Sodium Chloride Industrial

  • High Light

    multi effect salt production line

    ,

    sodium chloride industrial salt production line

    ,

    multi effect salt processing line

  • Production Capacity
    10-1000 Tons/day
  • Finished Product
    Table Salt, Industrial Salt, Etc.
  • Product Name
    Salt Production Line
  • Processing Type
    Dehydration And Drying
  • Warranty Period
    1 Year
  • Raw Material
    Sea Salt
  • Power
    380V/50HZ
  • Equipment
    Centrifuge, Dryer, Vacuum Filter, Etc.
  • Place of Origin
    china
  • Brand Name
    Hanpu
  • Certification
    ISO/CE
  • Model Number
    Evaporator
  • Minimum Order Quantity
    1
  • Price
    150000
  • Packaging Details
    wooden
  • Delivery Time
    90-120
  • Payment Terms
    L/C, D/A, D/P, T/T

Multi Effect Salt Production Line For Sodium Chloride Industrial

salt line automatic mvr falling film vacuum evaporator for salt making



Multi Effect Sodium Chloride Industrial Salt Line Automatic Mvr Falling Film Vacuum Multi Effect Salt Production Line For Sodium Chloride Industrial 0

Vacuum salt is a high-purity salt produced through the process of evaporation using vacuum technology. This method involves extracting salt from brine by evaporating the water under reduced pressure, resulting in pure salt crystals with minimal impurities.



MVR SYSTEM INTRODUCTION

Mechanical vaporization re-compression system, which is called MVR which principle is to compress the second steam generated by evaporator by high efficiency steam compressor; this process transfers electric energy to eating energy and higher the pressure and temperature of second steam. The second steam with higher temperature will be sent to evaporation room to heat the product for evaporation. So the latent heat of vaporization of the second steam can be circularly used. Making use of less energy which is the mechanical energy of compressor blade wheel as the compression heat pump, energy is added into the heating medium and is circularly used in heating process. Under this circumstance, no need to add first steam as heating medium.



MVR SYSTEM ADVANTAGE
(1)Lowest energy consumption and operation cost, electricity consumption of one ton water’s evaporation is 15-50kw. (2)Temperature difference is small, heating is gentle, the loss of product is less.
(3)Compact structure and lower building cost; plant area is 50% less than that of traditional evaporator.
(4)Surrounding is friendly, no gas and no steam.
(5)Good adaptability in low loading condition, flexibility of operation is good and has a longer service life.
(6)Consumption of circular water is low and energy saving is obvious.
(7)No fresh steam is needed.
(8)Evaporation can be carried out under 40℃ and equipment need not to be frozen, specially suitable for thermal activity products.
Multi Effect Salt Production Line For Sodium Chloride Industrial 1
Effective number
1
2
3
4
5
6
7
8
Steam consumption
(t steam/ t water)
~1.04
~0.53
~0.36
~0.28
~0.23
~0.19
~0.17
~0.15
Multi Effect Salt Production Line For Sodium Chloride Industrial 2
Multi Effect Salt Production Line For Sodium Chloride Industrial 3
Multi Effect Salt Production Line For Sodium Chloride Industrial 4
Application
Multi Effect Salt Production Line For Sodium Chloride Industrial 5
Application
Applied to multiple areas, such as: "zero release" solution for industrial waste water, Evaporation and concentration for process industry, food fermentation (aginomoto, citric acid, starch and sugar), fine chemical (pesticide, synthetic dyes, organic pigments, paints, spice and essence, cosmetic), chlorine chemical (salt water concentration), seawater desalt and metallurgical industry, etc.
Multi Effect Salt Production Line For Sodium Chloride Industrial 6
Company Profile
Multi Effect Salt Production Line For Sodium Chloride Industrial 7
Multi Effect Salt Production Line For Sodium Chloride Industrial 8
Multi Effect Salt Production Line For Sodium Chloride Industrial 9
Multi Effect Salt Production Line For Sodium Chloride Industrial 10
Established in 2019,Jiangsu Hanpu Machinery Engineering Technology Co., Ltd. is a subsidiary of Jiangsu Saideli Machinery Group.It is a professional enterprise engaged in the treatment of industrial waste water and gas,as well as evaporating crystallization, drying, filtration, and heat transfer in the field of multi-process production,together with the research and development and manufacturing of technical equipment.
Located in Junmin Road, Huangqiao Industrial Park, Taixing City, Jiangsu Province,the group has four major production bases, covering an area of 532800 square meters. Currently,there are 1580 employees, including 568 engineering technical personnel and professional technicians. We have fixed assets of 2 billion yuan and annual sales of 2.8 billion yuan.
The main products of the group include MVR evaporators, multi effect evaporators, centrifuges, reaction kettles, crystallizers, heat exchangers, PILLOW PLATES, Roots compressors, with various supporting fluid equipment.The enterprise has got ISO9001/2015 system certification, CE certification, ISO14001:2004 environmental management system certification, possesses A1 and A2 pressure vessel manufacturing qualifications, A2 pressure vessel design qualifications, and owns over 100 invention patents and utility model patent technologies. Also,we possess the right to self operate import and export trade.
The company's product quality, advanced technology, and comprehensive after-sales service have been widely recognized around the world, with a high market share. Various series of centrifuges account for 60% of the Chinese market and are exported to more than 50 countries and regions, including Germany, the United Kingdom, Italy, Denmark, Switzerland, the United States, Canada, Australia, Mexico, Brazil, Argentina, Chile, Colombia, Russia, Ukraine, Romania, India, Indonesia, Vietnam, Thailand, South Africa, Egypt, Cameroon, etc.
With the goal of "innovating products through technology, pursuing excellence in quality, serving customers with integrity and perfection", the company manufactures high-tech, highly automated, safe, and energy-saving equipment to become a first-class manufacturer of evaporation and fluid equipment in China.
Multi Effect Salt Production Line For Sodium Chloride Industrial 11
Multi Effect Salt Production Line For Sodium Chloride Industrial 12
Multi Effect Salt Production Line For Sodium Chloride Industrial 13
Multi Effect Salt Production Line For Sodium Chloride Industrial 14
Multi Effect Salt Production Line For Sodium Chloride Industrial 15
FAQ
1. who are we?
We are based in Jiangsu, China, start from 2019,sell to North America(30.00%),South America(20.00%),Western Europe(10.00%),Africa(10.00%),Northern Europe(7.00%),Oceania(5.00%),Eastern Europe(5.00%),Mid East(5.00%),South Asia(3.00%),Southeast Asia(3.00%),Southern Europe(2.00%). There are total about 11-50 people in our office.

2. how can we guarantee quality?
Always a pre-production sample before mass production;
Always final Inspection before shipment;

3.what can you buy from us?
Dimple Plate, Reactor, Centrifuge

4. why should you buy from us not from other suppliers?
The company has a national functional office and facilities as a scientific research bureau. The research center now has 5 doctor tutors, 8 professional engineers, 11 senior engineers, 42 engineers and 68 assistant engineers making it a leading specialized

5. what services can we provide?
Accepted Delivery Terms: FOB,CFR,CIF,EXW,DDP,DDU;
Accepted Payment Currency:USD,EUR;
Accepted Payment Type: T/T,L/C,PayPal,Western Union;
Language Spoken:English,Spanish
