Easy Cleaning Heat Transfer Pillow Plate Laser Welding

100m2(except for the sample)
MOQ
USD100/m2-USD300/m2
Price
Easy Cleaning Heat Transfer Pillow Plate Laser Welding
Features Gallery Product Description Request A Quote
Features
Specifications
Welding: Laser Welding Pillow Plate
Usage: Plate Heat Exchanger
Liquid Route: S Type
Function: Heat Transfer
Shape Mode: Single Or Double Drum
Feature: Condenser Evaporate
Plate Material: SS304/SS316/SS316L/Titanium
Heat Exchanger Type: Plate Heater Exchanger
High Light:

ISO pillow plate laser welding

,

Hanpu pillow plate laser welding

,

dimple plate steel SS316

Basic Infomation
Place of Origin: China
Brand Name: Hanpu
Certification: ISO
Model Number: Customized
Payment & Shipping Terms
Packaging Details: Standard export package, polywood, fumigated wood, filmed
Delivery Time: 30 days after down payment
Payment Terms: TT,.LC, Western Union
Supply Ability: 30000m2 per month
Product Description

Customizable Laser Welding Pillow Plate Heat Exchanger easy clean

Brief introduction

The Pillow Plate consists of two stainless steel sheets that are laser welded together by welding a custom circle weld pattern. The outside perimeter of the Pillow Plate is fully laser welded to create a pressure boundary. At the edges of the Pillow Plate, a contour is welded to create a pressure-tight part.

The pillow plate is hydraulically inflated by using water through a hydrostatic pump. Hydraulically inflating will guarantee for a safe inflation process. Other inflation processes can be used depending on the application.

The inflation process pressurizes the two sheets which allows the material to deform, a cavity will be created for use of a heat transfer medium. The Pillow Plate can be used with either liquids, steam or refrigerants.



Design

A Pillow Plate design is always custom-made. At first we look at your desired application. Do you need a plate with pillows on one side and a smooth surface on the other (for example, applications for cooling milk tanks or heat or cool applications in food or the pharmaceutical industry), then choose a single embossed Pillow Plate. The flat product side of the single embossed heat exchanger are used for sanitary product applications. Due to the precise welding process we can guarantee that no heat tint will occur after welding, the material is welded with the protective PVC foil in place.



Specification

Product Name Pillow plate heat exchanger
Material Stainless Steel
Color Nickel White
Standard DIN GB ISO JIS BA ANSI ASMI
Grade SUS201,SUS304,SUS316,DSS2205
Brade Hanpu
Length Customized



Features

1. Available in most materials, like stainless steel 304, 316L, 2205 and titanium
2. High operating pressures
3. High operating temperatures
4. No gaskets required
5. Corrosion resistant
6. Easily formed to fit the shape you need
7. Cutouts are easily provided
8. Thermally efficient types of heat transfer
9. Immersion heating and cooling.
10. Clamp-on heating, cooling, and temperature maintenance

Easy Cleaning Heat Transfer Pillow Plate Laser Welding 0

Easy Cleaning Heat Transfer Pillow Plate Laser Welding 1

Easy Cleaning Heat Transfer Pillow Plate Laser Welding 2



Applications

The application of pillow board is endless cooling and heating. If you have special wishes or requirements, please send an email to our engineers.



Company introduction

Jiangsu Hanpu Mechanical Technology Co., Ltd. is a project engineering company jointly established by Jiangsu Saideli Pharmaceutical Machinery Co., Ltd., Jiangsu Zhongyi Environmental Technology Co., Ltd., FERREO A/S in Denmark, Shanghai Jiaotong University and Nanjing Kingreat Machinery Co., Ltd. Hanpu main projects include but are not limited to: MVR evaporation system, powder washing salt and vacuum salt production project, oil tank sludge cleaning project, landfill leachate treatment project, plant/animal oil processing production line, urban wastewater treatment project, various wastewater treatment projects, and CBD oil extraction production line. Technical support and transfer of API product technology package. The main products are centrifuge series, multi-effect and MVR evaporation and crystallization equipment, laser welding heat transfer board, lithium battery material mixing equipment, pressure vessel and titanium, zirconium, nickel, and other non-standard special equipment.



Our services

1. 12 months guarantee period from machine arriving date.

2. Our technicians could be dispatched for overseas service.

3. 7*24 hours technical consultation.

4. Your workers could get trained both in our factory and yours.

5. Routine tracing till the machine work properly will be done timely.

6. Your suggestions or any comments & reflection would be treated in priority.

7. Marketing team will visit you during our visit in your country if you require.



Tips:lazer welding,pillow plate heat exchanger,plate heat exchanger stainless steel
