Name: Pillow Plates Used In Pillow Plate Heat Exchanger
Material: SS316L
Welding Technology: Laser Welding
Length: 1500mm
Thickness: 0.8-3mm
Application: Plate Heat Exchanger
High Light:

Double Embossed Pillow Plates

,

SS316L Pillow Plates

,

DIN Embossed Pillow Plate

Basic Infomation
Place of Origin: China
Brand Name: Hanpu
Certification: ISO
Model Number: 12*1.5m
Payment & Shipping Terms
Packaging Details: Standard export package, polywood, fumigated wood, filmed
Delivery Time: 30 days after down payment
Payment Terms: TT,.LC, Western Union
Supply Ability: 30000m2 per month
Product Description

 Double Embossed SS316L Pillow Plates Used in Pillow Plate Heat Exchanger

Introduction

Pillow Plates, consists of two stainless steel sheets that are laser welded together by laser welding machine. Then the plate is inflated by using water pressure, which creates a specific single or double embossed profile – the pillow plate, through which the cooling or heating is conducted. The thickness and the spot pattern are determined by the pressure requirements.



Features

1. Available in most materials, like stainless steel 304, 316L,2205 and titanium
2. High operating pressures
3. High operating temperatures

4. Thermally efficient types of heat transfer
5. Immersion heating and cooling.
6. Clamp-on heating, cooling, and temperature maintenance
7. Integral jacketing for heating and cooling
8. Custom heat exchanger design



Technical overview

Product Name Pillow plate
Material Stainless Steel
Color Nickle White
Standard DIN GB ISO JIS BA ANSI ASMI
Grade SUS201,SUS304,SUS316,TA2,Hastelloy
Brand Hanpu
Length Max.12000mm
Width Max.2000mm
Thickness of two sheets
Double Embossed Pillow Plate Single Embossed Pillow Plate
Pillow Plate 1.0mm +1.0mm Pillow Plate 1.0mm+2.5mm
Pillow Plate 1.2mm+1.2mm Pillow Plate 1.2mm+4.0-10mm
Pillow Plate 1.5mm+1.5mm Pillow Plate 1.5mm+4.0-10mm



Processing

Rolled Plate → Spread → Laser welding → Embossed → Finished



Product advantages

- Maintenance-free in dust loaded air
- No expensive interrupts as cleaning takes place during production

- Investment with short pay-back period

- Low maintenance cost

- Compact design and simple installation

- Good thermal operating efficiency due to high heat transfer coefficients

- Heat recovery with constant condensation
