Multi-Effect Evaporation Concentration Used Shell and Tube Heat Exchanger
Introduction
A shell and tube heat exchanger is a heat exchange device consists of a shell with a bundle of tubes inside it. According to design, shell and tube heat exchanger can be U-sharp tube heat exchanger and Straight tube heat exchanger.
Working principle
Two fluids of different starting temperatures, flow through the heat exchanger. One flows through the tubes (the tube side) and the other flows outside the tubes but inside the shell (the shell side). Heat is transferred from one fluid to the other through the tube walls.
Performance Comparison for Different Evaporator
| Item | Single effect evaporator | multi-effect evaporator | TVR evaporator | MVR evaporator |
| Energy consumption | energy consumption is much higher than others, 1ton water will consume 1Ton steam in theory | comparatively energy conservation | Base on traditional multi-effect evaporator, one more effect added, but higher pressure steam driven needed | The most energy saving technology for evaporator, but 10-40kwh power consumption |
| Floor space | Small | large | large | small |
| Energy sources | steam & power, need steam pipe network and boiler | steam & power, need steam pipe network and boiler | steam & power, need steam pipe network and boiler, need high pressure steam. | electricity, don't need pipe network, all the close-loop circulation system |
| Automaticity | Semi automatic | Full automatic operation, continuous evaporation | Full automatic operation, continuous evaporation | Full automatic operation, continuous evaporation |
Site picture
Part of Reference List
| No. | User | Application | Evaporation Capacity | Qty |
| 1 | Xinhua PHARMACEUTICAL Shouguang Co., Ltd | Ammouium Sulfate MVR Concentration | 17t/hr | 1 |
| 2 | Jiangxi Tonghe Pharmaceutical Co., Ltd | Sodium Chloride MVR Evaporation Crystallization | 5t/hr | 1 |
| 3 | Jiangsu Changqing agrochemical Co., Ltd | Sodium Chloride MVR Evaporation Crystallization | 10t/hr | 1 |
| 4 | Shijiazhuang Haili Fine Chemical Co., Ltd | Sodium Chloride MVR Evaporation Crystallization | 2t/hr | 1 |
| 5 | Suzhou Keda environmental protection engineering Co., Ltd | Sodium Chloride MVR Evaporation Crystallization | 1t/hr | 1 |
| 6 | Shijiazhuang hejia health care products Co., Ltd | Sodium Chloride MVR Evaporation Crystallization | 10t/hr | 1 |
| 7 | Hubei taisheng chemical Co., Ltd | Disodium hydrogen Phosphate MVR Evaporation Crystallization | 7t/hr | 1 |
| 8 | He'nan Xintiandi Pharmaceutical Co., Ltd | Ammonium chloride MVR Evaporation crystallization | 5t/hr | 1 |
| 9 | Taixing Jinyun dyestuff Co., Ltd | Dye MVR Concentration | 3t/hr | 1 |
| 10 | Changhuasheng(Taixing)Lithium Battery Material Co., Ltd | Sodium Chloride MVR Evaporation Crystallization | 5t/hr | 1 |
| 11 | Jiujiang fuda industry Co., Ltd | Ammonium Sulfate Evaporation Crystallization | 28t/hr | 1 |
| 12 | Zhejiang Jinke Peroxide Co., Ltd | Saline-alkali Evaporation crystallization | 10t/hr | 1 |
| 13 | LLC TD HALMEK | Lithium hydroxide single effect crystallization system | 4t/hr | 1 |
| 14 | Zhejiang xinhecheng special material Co., Ltd | Sodium chloride + sodium acetate evaporation crystallization | 6t/hr | 2 |
| 15 | Jiangxi Brother Medicine Co., Ltd | Nicotinic acid three-effect evaporation concentration | 9t/hr | 1 |
| 16 | Zhejiang Gramineae Technology Co., Ltd | Sodium chloride evaporation crystallization | 3t/hr | 1 |
