PPCF Automatic Horizontal Stainless steel Scraper Peeler Discharge Centrifuge for starch separation
Technical parameters
| Model |
Drum diameter (mm) |
Drum volume (L) | Loading capacity (kg) |
Max speed (r/min) |
| PPCF-53 | 600 | 41 | 53 | 2400 |
| PPCF-130 | 800 | 100 | 130 |
1500/ 1600 |
| PPCF-230/280 | 1050 | 210/260 | 230/280 |
1400/ 1700 |
| PPCF-350 | 1250 | 265 | 350 | 1200 |
| PPCF-430 | 1250 | 335 | 430 | 1200 |
| PPCF-650 | 1350 | 500 | 650 | 1200 |
Working principle
Feeding nitrogen or other inertgas into the host machine, after reaching the pre-determined content, when predetermined target is met and drum speed is suitable for feeding, feeding valve will be open automatically and product level detection begins to work.
When layer thickness is thick enough to reach the product detection slab, feeding valve closes to stop feeding. Under the effect of centrifugal force, most of the liquid in suspension is thrown out through filter cloth(or filter net) and the holes on drum wall then flows into mother liquid tank through horizontal liquid outlet(initial filter). With product dehydration going on, centrifuge will automatically slow down to washing speed according to technical requirement for washing.
Washing valve opens automatically With washing liquid rising to a certain height, washing valve closes and centrifuge speeds up automatically for further dehydration(secondary filter).
After a moment of operation,product will be fully dried. Then discharging will be in process.Then discharging valve opens and discharging cylinder begins to work when centrifuge automatically slows down to predetermined speed. With scraper rising spirally and automatically, solid product is scraped down into the hopper equipped with spiral discharger: With constant motion of spiral discharger, product is pushed out and discharged through valve.
Scraper rises closer to filter cloth with a certain distance till the bar on scraper device approaches proximity switch to stop
scraper rising then retreats quickly after a short stay(about 15s)then enters next cycle.
Discharging mode
Function Introduction
The machine is solid-liquid separation equipment which adopts continuous operation and intermittent discharging.
It is controlled by PLC.It regulates speed by frequency convertor, braking system adopts dynamic braking and regenerative braking.
Through such procedures as product level detection, speed, inspection, shaft temperature and vibration monitoring, the whole separation process is automatic circulative work(including feeding, dehydration, washing, discharging and etc.)
Also manual operation mode is available which can be changed over from full-automation mode by customer's will.
Guarantee
Hanpu Centrifuge has been dedicated to producing machinery and types of equipment and carrying out facility construction, pursuing the best quality, and producing the best product at the same time.We are committed to rewarding you with better quality in return for our interest in and faith. We will do our utmost for one more stepping forward, based on our infinite services and trust in customers.
Our services
1. 12 months guarantee period from machine arriving date.
2. Our technicians could be dispatched for overseas service.
3. 7*24 hours technical consultation.
4. Your workers could get trained both in our factory and yours.
5. Routine tracing till the machine work properly will be done timely.
6. Your suggestions or any comments & reflection would be treated in priority.
7. Marketing team will visit you during our visit in your country if you require
