Scraper Discharging Continuous Peeler Type Centrifuge

Scraper Discharging Continuous Peeler Type Centrifuge

  • High Light

    Horizontal peeler type centrifuge


    Siphon peeler type centrifuge


    Corn Starch filtration centrifuge

  • Product Name
    Continuous Filtration Centrifuge Machine
  • Type
  • Speed
  • MOC
    SS304,316 As Option
  • Operation
    Continuous Automatic
  • Collocation
    Hydraulic System,Level Detector
  • Equipped
    PLC System, Inverter
  • Base Concrete
  • Place of Origin
  • Brand Name
  • Certification
  • Model Number
  • Minimum Order Quantity
    1 set
  • Price
    USD60000-100000/set FOB Shanghai
  • Packaging Details
    Standard export package,
  • Delivery Time
    60-75 days after down payment
  • Payment Terms
    L/C, T/T, Western Union
  • Supply Ability
    300 sets/month

Scraper Discharging Continuous Peeler Type Centrifuge

                                      Scraper Discharging continuous Filtration Centrifuge Machine For Corn Starch

Function description
This machine is controlled by PLC and regulates speed by frequency control,braking system applies dynamic braking and regenerative braking,the whole separation process is automatic cycle operation and manual operation mode is applicable to be changed over from automatic operation mode.
PPCC Series automatic siphon centrifuge is more suitable for separating such product as small solid phase granularity and which is hard to be separated.It is widely used in pharmaceutical,Chemical and foodstuff industry(e.g.starch,calcium phosphate.Sodium bicarbonate.)


 Working principles
When predetermined target is met and drum speed is suitable for feeding, feeding valve will be open automatically and product level detection begins to work.When layer thickness is thick enough to reach the product detection slab, feeding valve closes to stop feeding.
Under the effect of centrifugal force, most of the liquid in suspension is thrown out through filter cloth and then flows into mother liquid tank through horizontal liquid outlet.With product dehydration going on, centrifuge will automatically slow down to washing speed according to technical requirement for washing.
Washing valve opens automatically. With washing liquid rising to a certain height, washing valve closes and centrifuge speeds up automatically for further dehydration(secondary filter).
After operation, product will be fully dried. Then discharging valve opens and discharging cylinder begins to work when
centrifuge automatically slows down to predetermined speed.
With scraper rising spirally and automatically,solid product is scraped down into the hopper equipped with spiral discharger: With constant motion of spiral discharger, product is pushed out and discharged through valve.
Scraper rises closer to filter cloth with a certain distance till the bar on scraper device approaches proximity switch to stop scraper rising then retreats quickly after a short stay(about 15s)then enters next cycle.



Drum diameter


Drum volume (L) Loading capacity (kg)

Max speed


Max separation factor

Motor power

PPC-53 600 41 53 2400 1931 18.5
PPC-130 800 100 130





PPC-230/280 1050 210/260 230/280





PPC-350 1250 265 350 1200 1006 55
PPC-430 1250 335 430 1200 1006 55
PPC-650 1350 500 650 1200 1086 55
PPC-900 1600 700 900 950 808 90
PPC-1000 1600 840 1000 950 808 90
PPC-1800 1800 1390 1800 900 815 132


It is fully conformed to GMP,CGMP and meet the requirements of asepsis raw medicine production.
♦ With absolute isolation between power area and process area.It is suitable for occasion when customer requires high quality cleaning to avoid the contamination to product.
♦ The out shell bucket can be opened, so the whole internal parts can be observed and easy for touch wiping and cleaning.
♦ Perfect CIP system can be carried out to wash the internal parts of centrifuge to avoid cross contamination which are not easy to clean.
♦ Unique pneumatic counter-pulse device is equipped, which can remove remnant filter cake as much as possible.
♦ Totally-enclosed structure equipped with inert gas protection is adopted to be used in ex-proof 1 section.
♦ The automatic residual cakes removing device is optional (have owned the national patent).
